Full Length 1600 mm (5.25 ft)
Full Width 850 mm (2.79 ft)
Full Height 1450 mm (4.76 ft)
Useful width 270 mm (0.89 ft)
Useful length 740 mm (2.43 ft)
Cooking area 0.2 m²
Electricity : 400VAC-3x50Hz
Power : 11 kW / 16 A
Full Length 2450 mm (8.04 ft)
Full Width 1355 mm (4.44 ft)
Full Height 1453 mm (4.77 ft)
Useful width 400 mm (1.31 ft)
Useful length 1000 mm (3.4 ft)
Cooking area 0.4 m²
Electricity : 400VAC-3x50Hz
Power : 34 kW / 50 A
Full Length 3450 mm (11.32 ft)
Full Width 1355 mm (4.44 ft)
Full Height 1453 mm (4.77 ft)
Useful width 400 mm (1.31 ft)
Useful length 2000 mm (6.56 ft)
Cooking area 0.8 m²
Electricity : 400VAC-3x50Hz
Power : 65 kW / 95 A
Full Length 3450 mm (11.32 ft)
Full Width 1600 mm (4.44 ft)
Full Height 1453 mm (4.77 ft)
Useful width 600 mm (1.97 ft)
Useful length 2000 mm (6.56 ft)
Cooking area 1.2 m²
Electricity : 400VAC-3x50Hz
Power : 98 kW / 144 A
We understand that not every commercial production kitchen has a dedicated technical team. That’s why TWIN-COOK is designed for easy-going maintenance. No tools are required for day-to-day cleaning and upkeep, making it a perfect fit for commercial kitchens without on-site technicians.
TWIN-COOK is a scaled-down version of processing systems for semi-industrial and large-scale industrial food production. Leveraging direct contact heat transfer technology, that accomodates larger process areas to meet growing production volumes.
Key parameters such as temperature, time, thickness, and product outcomes such as core temperature, weight loss, and appearance remain the same irrespective of the system size. This uniformity ensures identical settings across different scales of production.
TWIN-COOK is designed to deliver an output of approximately 75 kg (165 lbs) per hour. Subsequent system sizes produce 150 kg (330 lbs), 300 kg (660 lbs), and beyond. The scalability of these systems allows for expansion, accomodating production volumes exceeding 6000 kg (13200 lbs) per hour, all while maintening process parameters and consistent product results.
As a member of our group, CelsiusFOOD specializes in the design and manufacture of larger systems for industrial needs.
Visit CelsiusFOOD to learn more about our larger production systems for the food industry.
The non-stick PTFE coated conveyor belts wears out and need to be replaced after some time. The largest single factor affecting the service life of non-stick conveyor belts is the operation temperature. Ingredients such as sucrose, dextrose, starch and protein affects the logevity.
As a rule of thumb, PFTE coated Teflon belts need to be replaced after about 300 hours. The cost of non-stick conveyor belts rarely exceeds 0.0019 Euros per kilo (0.0024 USD par lbs) of raw product.
Get in touch if you have any questions about PTFE coated conveyors of you need to order a set of belts.
Our support does not end at the purchase of your TWIN-COOK. We help you when there is anything wrong with your equipment.
Co,sult the spare part drawings in the Operation Manual or contact us for support. We keep most parts in stock and ship stock-parts within 24 hours.
